KOMATSU D155PX-8 LGP
- Share
Get a quote
2024
Komastu
D155PX-8 LGP
New
Ontario
Torque converter dozers for your heavy jobs
For pushing massive loads on soft ground, the D155PX-8 LGP (low ground pressure). An 8-roller undercarriage with track shoe size up to 38” (965 mm) wide for outstanding traction and balance with exceptional floatation. Optional extended wear life undercarriage with 34” wide PLUS (Parallel Link Undercarriage System) rotating bushing track shoes available.
- Engineered for powerful dozing
- Excellent blade capacity
- Quiet cab with smooth ride and great visibility
Engine
| Model | Komatsu SAA6D140E-7** |
| Type | 4-cycle, water-cooled, direct injection |
| Aspiration | Komatsu Variable Geometry Turbocharged, air-to-air aftercooled, cooled EGR |
| Number of cylinders | 6 |
| Bore x stroke | 5.51 x 6.50 in |
| Piston displacement | 930 in³ |
| Governor | Mid-range, electronic |
| Horsepower: | |
| SAE J1995 - Gross | 360 HP |
| ISO 9249 / SAE J1349* - Net | 354 HP |
| Rated rpm | 1,900 rpm |
| Fan drive type | Hydraulic |
| Lubrication system: | |
| Method | Gear pump, force lubrication |
| Filter | Full-flow |
| *Net horsepower at the maximum speed of radiator cooling fan: 320 HP | |
| **EPA Tier 4 Final emissions certified |
TORQFLOW Transmission
Komatsu's automatic TORQFLOW transmission consists of a water-cooled, 3-element, 1-stage, 1-phase, torque converter with lockup clutch, and a planetary gear, multipledisc clutch transmission which is hydraulically actuated and force-lubricated for optimum heat dissipation. Equipped with gearshift lock lever and neutral safety switch.
| Travel speed: | |
| 1st Gear forward | 2.4 mph |
| 1st Gear reverse | 2.9 mph |
| 2nd Gear forward | 3.5 mph |
| 2nd Gear reverse | 4.2 mph |
| 3rd L Gear forward | 4.7 mph |
| 3rd L Gear reverse | 5.7 mph |
| 3rd Gear forward | 7.2 mph |
| 3rd Gear reverse | 8.7 mph |
Final drive
Blades
| Angle Blade | |
| Capacity | 9.6 yd3 |
| Width at cutting edge | 19 ft. 0 in |
| Height | 4 ft. 5 in |
| Tilt, max angle | 9.5 degrees |
| Tilt, max dimension | 38 in |
| Weight | 14700 lbs. |
| Semi-u blade | 10.3 US gal |
| Capacity | 12.9 - 15.7 yd3 |
| Width over end bits | 15 ft. 1 in |
| Weight ‘AR” spec / non ‘AR” | 12732 lbs. / 11,114 lbs. |
Undercarriage
Suspension: Oscillation-type with equalizer bar and forward mounted pivot shafts
Track roller frame: Monocoque, high-tensilestrength steel construction
Fixed mounted 8-roller undercarriage
Lubricated track rollers are rigid mounted to the track frame.
Track shoes
Lubricated tracks. Unique dust seals for preventing entry of foreign abrasives into pin-to-bushing clearance for extended service. Track tension easily adjusted with grease gun.
| Number of shoes (each side) | 45 |
| Grouser height | 3.1 in |
| Shoe width (standard/maximum) | 38 in |
| Ground contact area | 12,096 in² |
| Ground pressure (tractor only) | 7.67 psi |
| Number of track rollers (each side) | 8 |
| Number of carrier rollers (each side) | 2 |
Service refill capacities
| Fuel tank | 165 US gal |
| Coolant | 27.5 US gal |
| Engine oil | 9.8 US gal |
| Damper | 0.4 US gal |
| Transmission, bevel gear, and steering system | 23.8 US gal |
| Final drive (each side) | 8.2 US gal |
| DEF tank | 10.3 US gal |
| Hydraulic oil capacity | 25.1 US gal |
Operating weight (approximate)
| Tractor weight | 85,100 lbs. |
| Operating weight | 92,820 lbs. |
| Ground pressure | 7.67 psi |
Hydraulic system
Standard rear Closed-center load sensing system (CLSS) designed for precise and responsive control, and for efficient simultaneous operation. High flow hydraulics for towing winch is standard. Base machine is equipped with dual tilt and pitch dozer hydraulics for semi-u blade. Angle blade is equipped with dual tilt, no pitch.
Hydraulic control unit:
All spool control valves externally mounted beside the hydraulic tank.
Variable piston pump with capacity (discharge flow) of 85.9 US gal for steering and 47.6 US gal for implement at rated engine rpm.
Relief valve setting
. . . for implement 3,980 psi
. . . for steering 5,550 psi
<
| Control valves: | ||
| Spool control valve for SIGMADOZER, Semi-U tilt dozer and Full-U tilt dozer. | ||
| Positions: | Blade lift | Raise, hold, lower, and float |
| Blade tilt | Right, hold, and left | |
| Hydraulic cylinders | Double-acting, piston | |
| Number of cylinders | Bore | |
| Blade Lift / 2 | 4.33 in | |
| Blade Tilt (Dual tilt) / 2 | 6.30 in | |
| Blade Tilt (Single Tilt) / 1 | 6.30 in | |
| Hydraulic oil capacity (refill): | ||
| Angle dozer | 25.1 US gal | |
| Semi-U dozer | 25.1 US gal |
- Air cleaner, double element with dust indicator
- Alternator, 140 ampere/24V
- Backup alarm
- Batteries, 200 Ah/2 x 12V
- Battery disconnect switch
- Blade lift cylinders with double dust seal
- Color monitor, LCD
- Decelerator pedal
- Engine hood
- Engine idle auto shutdown with adjustable timer
- Engine intake centrifugal precleaner
- Engine, gull-wing side covers
- Engine shutdown secondary switch
- Exhaust pipe with raincap
- Fast fuel provision
- Fenders
- Front pull hook
- Fuel pre-filter and primary filter
- Grid heater starting aid in cold weather
- High mount foot rests
- Horn, warning
- Hydraulic driven radiator cooling fan with manual reverse clean mode
- Hydraulics for dual tilt and pitch dozer
- Hydraulics for ripper VGR/MSR
- KOMTRAX® Level 5
- Komatsu Diesel Particulate Filter (KDPF)
- Komatsu Variable Geometry Turbocharger (KVGT)
- Komatsu Selective Catalytic Reduction (SCR)
- Locks, filler caps and covers
- Oil pressure check ports for power train
- PM service connector
- Radiator mask, double door, heavy-duty, hinged, perforated
- Radiator reserve tank
- Rear cover
- ROPS cab (3,131 lb)**
- Air conditioner/heater/defroster
--Pressurized
--Condenser remote mounted - Cab accessories
- Work lights
--2 front, hood mounted
--2 front, cab mounted
--2 rear, fender mounter
--2 rear, cab mounted
--1 rear, for ripper point - Seat, air suspension, fabric, heated, low back, rotates 12.5° to right, headrest
- Seat belt, 3", retractable
- Seat belt indicator
- Sealed electrical connectors
- Starting motor, 24V
- Steering system: Hydrostatic Steering System (HSS)
- Torque converter with auto lock-up
- Track roller guards, end sections
- Track shoe assembly
- Sealed and lubricated
- Transmission with auto/manual shift modes
- Underguards, heavy duty
- Hinged belly pans
- Water separator, fuel
- Wide core cooling package, 6 fins per inch spacing
Blades
- Manual Angle Power Tilt 9.6 yd3
- Semi-U dual tilt and pitch 12.9 yd3
- Semi-U AR dual tilt and pitch 15.7 yd3
Shoes
- 38” Extreme Service, SALT
- 34” Moderate Service, PLUS
Rear Attachment
- HD long drawbar 528 lb
- HD Counterweight 9-plate with rigid drawbar, 7,860 lb
Abrasion Resistant Package
- 34" 860mm PLUS tracks
- AR steel liner on semi-u blade
- Spill guard extension on semi-u
- Grading skid plates on semi-u
- Radiator mask reinforcement
- Cooling fan hard coated steel
- Radiator core guard
- LED work lamps
- Centralized grease zerks
- Air suspension seat heated/cooled no rotate
