KOMATSU D61EXi-24
- Share
Get a quote
2024
Komastu
D61EXi-24
New
Ontario
A workhorse for your fleet
Every dozer fleet is built on the workhorses … versatile, powerful machines you rely on day after day, year after year. This dozer was designed from the ground up to fill that role. The Tier 4 Final engine and electronically controlled hydrostatic transmission keep fuel use remarkably low without sacrificing power. A standard parallel link undercarriage system features rotary bushings engineered to extend wear life and lower repair/maintenance costs. In addition to economy and power modes, a high engine rpm H mode helps operators maintain ground speed while operating under heavy loads.
- Get new operators up to speed quickly
- Go from mass ex to finished grading faster than ever
- Fully integrate 3D design data into your machines
- Empower operators to work efficiently, pass after pass
Engine
| Model | Komatsu SAA6D107E-3* |
| Type | 4-cycle, water-cooled, direct injection |
| Aspiration | Komatsu Variable Geometry Turbocharged, air-to-air aftercooled, cooled EGR |
| Number of cylinders | 6 |
| Bore x stroke | 4.21 x 4.88 in |
| Piston displacement | 408 in³ |
| Governor | All-speed and mid-range, electronic |
| Horsepower: | |
| SAE J1995 - Gross | 170 HP |
| ISO 9249 / SAE J1349 - Net | 168 HP |
| Hydraulic fan at maximum speed | 152 HP |
| Rated rpm | 2,200 rpm |
| Fan drive type | Hydraulic |
| Lubrication system: | |
| Method | Gear pump, force lubrication |
| Filter | Full-flow |
| *EPA Tier 4 Final emissions certified |
Hydrostatic transmission
Dual-path, hydrostatic transmission provides infinite speed changes up to 9.0 km/h 5.6 mph. The variable capacity travel motors allow the operator to select the optimum speed to match specific jobs. Travel control lock lever and neutral switch.
| Travel speed (quick shift mode)* | Forward | Reverse |
| 1st | 0-2.1 mph | 0-2.5 mph |
| 2nd | 0-3.5 mph | 0-4.0 mph |
| 3rd | 0-5.6 mph | 0-5.6 mph |
| Travel speed (variable mode) | 0-5.6 mph | 0-5.6 mph |
*Quick shift speeds are adjustable in the monitor.
Final drive
Steering system
PCCS joystick control for all directional movements. Pushing the joystick forward results in forward machine travel, while pulling it backward reverses the machine. Simply tilt the joystick to the left or right to make a turn. Tilting the joystick fully to the left or right activates counter-rotation. HST eliminates steering clutches and brakes, providing smooth powerful turns. Fully electronic control enables smooth control. The PCCS utilizes shift buttons to increase and decrease speed.
| Minimum turning radius | 83 in |
Undercarriage
Track roller frame: Monocoque, large section, durable construction
Rollers and idlers: Lubricated track rollers
Lubricated tracks
Parallel Link Undercarriage System (PLUS) with lubricated rotating bushings for extended system wear life and lower maintenance costs. Track tension is easily adjusted with grease gun.
| Number of track rollers (each side) | 8 |
| Type of shoes (standard) | Single grouser |
| Number of shoes (each side) | 46 |
| Grouser height | 2.3 in |
| Shoe width (standard) | 24 in |
| Ground contact area | 5,887 in² |
| Ground pressure (with dozer, ROPS canopy): |
6.29 psi |
| Track gauge | 6 ft. 3 in |
| Length of track on ground | 10 ft. 5 in |
Service refill capacities
| Coolant | 11.9 US gal |
| Fuel tank | 98.3 US gal |
| Engine oil | 7.2 US gal |
| Hydraulic tank | 26.7 US gal |
| Final drive (each side) | 2.2 US gal |
| DEF tank | 5.4 US gal |
Operating weight (approximate)
| Tractor weight: Including ROPS (ISO 3471) cab, C frame for PAT dozer, rated capacity of lubricant, coolant, full fuel tank, operator and standard equipment. |
38,911 lbs. |
| Operating weight: Including PAT dozer, ROPS (ISO 3471) cab, operator, standard equipment, rated capacity of lubricant, coolant and full fuel tank. |
41,094 lbs. |
Hydraulic system
Closed-center Load Sensing System (CLSS) designed for precise and responsive control, and for efficient simultaneous operation.
Hydraulic control unit:
All spool control valves externally mounted remote to the hydraulic tank. Piston-type hydraulic pump with capacity (discharge flow) of 171 L/min / 45 US gpm at rated engine rpm.
| Relief valve setting | 3,974 psi |
| Hydraulic cylinders | Double-acting, piston type |
| Hydraulic cylinders / Number of cylinders | Bore |
| Blade lift / 2 | 4 in |
| Blade tilt / 1 | 5 in |
| Blade angle / 2 | 4 in |
| Hydraulic oil capacity (refilling): | |
| Power angle tilt dozer | 26.7 US gal |
| Control valves: | |
| 3-spool control valve for Power Angle Tilt dozer | |
| Positions: | |
| Blade lift | Raise, hold, lower, and float |
| Blade tilt | Right, hold, and left |
| Blade angle | Right, hold, and left |
| Additional control valve required for ripper | |
| Positions: | |
| Ripper lift | Raise, hold, and lower |
- Air cleaner, double element with dust indicator
- Alternator, 90 ampere/24V
- Backup alarm
- Batteries, 200 Ah/2 x 12V
- Battery disconnect switch
- Blade lift cylinders
- Color monitor, LCD
- Curved exhaust pipe
- Decelerator pedal (single pedal)
- Engine hood
- Engine intake centrifugal precleaner
- Engine, swing open side cover
- Engine shutdown secondary switch
- Fluid sampling ports
- Front pull hook
- High mount foot rests
- Horn, warning
- Hydraulic driven radiator cooling fan with reverse clean mode
- Hydraulics for rear equipment
- intelligent Machine Control 2.0
- KOMTRAX
- Komatsu Diesel Particulate Filter (KDPF)
- Locks, filler caps and covers
- Radiator mask, heavy-duty, swing up
- Radiator reserve tank
- Remote mounted equalizer bar greasing
- ROPS cab**
- Air conditioner
- Cab accessories
- 12V power supply (2 ports)
- Cup holder
- Rearview mirror
- Rear view monitoring (1 camera)
- Bluetooth/USB compatible radio with remote AUX plug (3.5 mm)
- 76 dBA
- LED worklights
- Seat, air suspension, fabric, heated low back, headrest
- Seat belt, 76 mm 3", retractable
- Seat belt indicator
- Sealed electrical connectors
- Side-by-side rear mounted cooling package
- Starting motor, 5.5 kW/24V
- Steering system, hydrostatic
- Tie off points standard (ISO 14567)
- Track roller guards, center and end sections
- Track shoe assembly
– Heavy-Duty lubricated rotary bushing (PLUS) track- 24" single grouser shoe (EX)
- 34" single grouser shoe (PX)
- Transmission with variable and customizable quickshift
- Transmission, hydrostatic
- Underguards, heavy duty
- Engine
- Transmission
- Variable Geometry Turbocharger (VGT)
- Water separator
* Dozer assembly and rear mounted equipment are not included in base machine standard equipment
** Cab meets ROPS and FOPS Level 2 standards
- Dozer assembly
- Drawbar, long type
- Track roller guard, full length
Multi-shank ripper
- Weight: 3,874 lb
- Beam length: 7'1"
- Maximum lift above ground: 1'8"
- Maximum digging depth: 2'2"
